TM017FDH03 TIANMA 1.8 inch 128×160 250 cd/m² INDUSTRIAL LCD DISPLAY

  • 1
  • 2

Brand Name : TIANMA

Model Number : TM017FDH03

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 3000PCS

Packaging Details : STANDARD PACKING

MODEL NUMBER : TM017FDH03

BRAND : TIANMA

SIZE : 1.8 inch

RESOLUTION : 128(RGB)×160 115PPI

BRIGHTNESS : 250CD/M2

Lamp Type : WLED

SIGNAL LNTERFACE : LVDS

Viewing Angle : 45/45/50/20 (Typ.)(CR≥10

TEMPERATURE RANGE : Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C

Contact Now

TIANMA TM017FDH03 Application Details

Basic Information : Brand Model TM017FDH03
Type LCM a-Si TFT-LCD Used For
Screen Size 1.8" Alias -
Environment : Storage Temp. -30 ~~ 80 °C Operating Temp. -20 ~~ 70 °C
RoHS Vibration -
Typical Features :


Remarks : CPU 8 bits

TIANMA TM017FDH03 Mechanical Details

Pixel Features : Resolution 128(RGB)×160 Dot Pitch(mm) 0.073×0.219 (H×V)
Pixel Format RGB Vertical Stripe Pixel Pitch(mm) 0.219×0.219 (H×V) [115PPI]
Mechanical Size : Active Area(mm) 28.032(H) × 35.04(V) Bezel Area(mm) -
Outline Dim.(mm) 34.7(H) × 47(V) Depth(mm) 2.60
Outline Features : Form Style Flat Rectangle Outline Shape
Aspect Ratio 4:5 (H:V) Orientation Portrait type
Other Spec : Weight 6.70g Treatment Clear, Hard coating (3H)

TIANMA TM017FDH03 Optical Details

Basic Information : Luminance(cd/m²) 250 (Typ.) Contrast Ratio 350:1 (Typ.) (Transmissive)
Viewing Angle 45/45/50/20 (Typ.)(CR≥10) Display Mode TN, Normally White, Transmissive
Best View on 6 o'clock Response(ms) 30 (Typ.)(Tr+Td)
Color Performance : White Coordinate X:0.288; Y:0.308 Display Colors 65K/262K
Color Temperature 8480K White Uniformity 1.25/1.33 (Typ./Max.)(9 points)
1931 Color Gamlt : NTSC Ratio 43% sRGB 59% coverage
Adobe RGB 44% coverage DCI-P3 44% coverage
Rec.2020 32% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

TIANMA TM017FDH03 Electronics Details

Reverse Scan : No
Driver IC : Built-in HX8353-C

TIANMA TM017FDH03 Interface Details

Signal Electrical : Voltage Supply 2.8/2.8V (Typ.)(VDD1/VDD2) Current Supply -
Signal Type : CPU Signal Voltage -
Interface Features : Position - Type FPC
Interface Detail : Brand Model Quantity Pins Pitch Pin Configuration
1 pcs 25 pins 0.8 mm

TIANMA TM017FDH03 Backlight Details

Backlight Features: Shape Parallel Type WLED Position Edge light type
Replacement - Quantity 1S2P Life Time 20K(Typ.) (Hours)
Lamp Electrical : Voltage Supply 3.2V (Typ.) Current Supply 15mA (Typ.)
Consumption 96mW (Typ.)
Interface Features : Position - Type Included in panel signal interface
Backlight Driver : No

TIANMA TM017FDH03 Packing Details

Package Box : Quantity Weight Box Size
792 pcs / box 11.10 Kgs 544×365×250 mm (L×W×H)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
